Pedal Steel Guitar Changer Finger

A number of stock steel guitar pedals have two holes for pedal rod connectors so this was easy to do.

Pedal steel guitar changer finger.

The changer is the heart of a pedal steel guitar. Which rotates the bell crank finger which pulls the pull rods which pulls the changer finger. In this configuration the raise finger goes up and around the bridge pin finger shaft and resides next to the control finger. The pedal rods rotate the cross rods and are stopped by the pedal stops.

The pedal stop may or may not be adjustable on your steel guitar. On guitars with modern all pull changers there are 2 basic types of mechanisms. Makin chips changer finger stops. Hold it there and tune with the left hand at the keyhead tune the string to the note you want it hit when you raise it.

I tried something similar to that but ended up using two cables to a pedal where there were two pulls involved. It contains 1 rivet which connects the raise and lower fingers. Tune the changer for the pedal or knee lever that you are setting up reach under the guitar and push the bridge finger for one of the strings you plan to raise left all the way until it hits the body of the guitar. On the underside of the body you ll see the pedal rods attached to cross rods.

This movie shows ross shafer making changer finger stops for the new sierra pedal steel guitar. Doing that seemed to lessen the force needed to raise the strings. Our stainless steel finger is manufactured by a unique process by which powdered metal is formed under extreme pressure and high heat to create a part much harder than its original starting material. Most steel guitar companies use aluminum for this part.

The cables were attached to right and left sides of the pedal.
